100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering

Product Details

Place of Origin: china

Brand Name: toktos

Model Number: HJ10-A

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $135

Payment Terms: T/T

Supply Ability: 99999

Get Best Price
Highlight:

HJ10-A Spot Welding Machine For Jewellery

,

100A Spot Welding Machine For Jewellery

,

100A gold spot welding machine

Dimensions:
28*16*22
Voltage:
110/220V
Power (kW):
600W
Usage:
Spot Welding
Model:
100A
Product Size:
248*255*130mm
Welding Range:
0.5-2MM
Material:
Metal
Dimensions:
28*16*22
Voltage:
110/220V
Power (kW):
600W
Usage:
Spot Welding
Model:
100A
Product Size:
248*255*130mm
Welding Range:
0.5-2MM
Material:
Metal
100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering

100A HJ10-A Jewelry Spot Welding Machine Welding Equipment Jewelry Making Tools



100A jewelry spot welding machine gold and silver copper ring necklace welding machine handheld laser pulse welding machine

Product introduction:
Spot welder can be used for platinum, gold, gold, silver, steel, rapid welding, ring, melon button, precision wire soldering, direct soldering without solder powder, smooth solder joints. Using the principle of plasma high-frequency discharge, a molten pool is formed instantaneously at the metal welding joint. Adjust the output power according to the different sizes of the wires. The welded workpiece is smooth, firm, fast, and efficient.

Installation and commissioning:
1. The electrode is connected to the output negative pole, and the electrode holder is connected to the output positive pole.
2. The tungsten needle can be sharpened on the grinder and operated by the principle of tip discharge.
3. The diameter of the tungsten needle is 1.5mm.

Steps:
1. Turn on the power and turn on the power switch.
2. Adjust the power knob, which is divided into coarse adjustment and fine adjustment. The scale value can be adjusted arbitrarily according to the work requirements.
3. Hold the workpiece with tweezers, and the workpiece interface is aligned with the tungsten needle (distance is 5mm). The workpiece cannot be touched.
4. Use your foot to step on the foot switch and remove the foot.

Precautions:
1. The foot can't step on the foot switch for a long time. If you step on it, the machine will be short-circuited and the internal circuit will be burnt out.
2. Please use this machine for precision.
3. Flash is harmful to the eyes, please take protective measures when using.
4. When stepping on the foot switch, do not touch the metal parts of the tungsten needle and the tweezers at the same time, otherwise there will be a needle sensation.
5 non-professionals please do not dismantle, there is high pressure.

Package contains:

100A spot welder*1
Foot switch*1
Tungsten needle *1
Clip *2
Welding handle *1

Product Size:248*255*130mm

Product Weight:6kg

Technical Parameters

Model: 100A

Input voltage: AC220/110 (V)

Power: 600W

Maximum welding thickness: 1.6 (mm)



100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering 0100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering 1100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering 2100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering 3100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering 4

100A HJ10-A Spot Welding Machine For Jewellery precision wire soldering 5



Place of Origin
China
Dimensions
28*16*22CM
Usage
spot welding
Voltage
110V/220V
Warranty
1 Year
Key Selling Points
Low Maintenance Cost
Power (kW)
0.6KW
Weight (KG)
6.5KG
After-sales Service Provided
Online support
Certification
CE
Welding Range
0.5-2MM
Welding Current
100A
